HYDRO POINT WATER WELL DRILLINGCONTRACTING LLC
COMPLETE EQUIPMENT RANGE
Drilling rigs,
matched to your ground.
Explore 18 crawler and truck-mounted configurations for water wells, geothermal work and demanding specialist applications.
19drilling rig configurations
FYX180
1 / 19
RUBBER CRAWLER WATER WELL DRILLING RIG
FYX 180
Compact rubber-track rig designed for water or air drilling with easy site mobility and reduced impact on hard surfaces.
ENGINE POWER55 kW
DRILLING DEPTH180 m
HOLE DIAMETER140–254 mm
LIFTING FORCE12 T
COMPLETE SPECIFICATION
FYX 180 technical data
Machine weight4.5 T
Drill pipe diameterØ76 / Ø89 mm
Hole diameter140–254 mm
Drill pipe length1.5 / 2 / 3 m
Drilling depth180 m
Rig lifting force12 T
Single advance3.3 m
Rapid rise speed20 m/min
Travel speed2.5 km/h
Fast feed speed40 m/min
Maximum climbing angle30°
Loading width2.4 m
Engine power55 kW
Winch lifting force—
Working air pressure1.7–2.5 MPa
Swing torque3,200–4,600 N·m
Air consumption17–31 m³/min
Overall dimensions3,950 × 1,630 × 2,250 mm
Swing speed45–70 rpm
Penetration efficiency10–35 m/h
High-leg stroke1.4 m
EngineQuanchai diesel
Specifications are catalogue values and may vary by configuration. Contact Hydro Point to confirm availability and the correct setup for your geological conditions.
